400m Depth Pneumatic Drilling Rig Rubber Belt Track Household

  • 1
  • 2

Type : hydraulic crawler drilling machine

Max. Drilling depth : 400

Dimension(L*W*H) : 6m×2m×2.5m

Power Type : 89

feature : high drilling efficiency

Drilling diameter : 105-300mm

Rod length : 6M

Lifting force : 22T

Fast lifting speed : 24m/min

Warranty : 1 Year

Brand Name : ShiTan

Model Number : ST400

Certification : ISO9001

Place of Origin : China

MOQ : Negotiation

Price : Negotiation

Payment Terms : L/C, D/A, T/T, Western Union

Supply Ability : 10000year

Delivery Time : Within 7-12 days

Packaging Details : Wooden box

Contact Now

400m Depth Pneumatic Drilling Rig Rubber Belt Track Household
Key Specifications
Attribute Value
Type Hydraulic crawler drilling machine
Max. Drilling Depth 400m
Dimensions (L×W×H) 6m × 2m × 2.5m
Power Type 89
Drilling Diameter 105-300mm
Rod Length 6M
Lifting Force 22T
Fast Lifting Speed 24m/min
Warranty 1 Year
Product Overview

The ST400 Crawler Mounted Drill Rig is a high-efficiency, versatile drilling solution designed for water wells, agricultural irrigation, and geothermal applications. Its robust hydraulic system delivers exceptional performance in mountainous terrain and rock formations.

Technical Parameters
Parameter Specification
Model ST400
One-time Advance Length 3000/6000mm
Walking Speed 6km/h
Climbing Ability 25°
Min. Ground Clearance 300mm
Working Air Pressure 1.7-3.5Mpa
Air Consumption 17-35m³/min
Main Power 100KW/6 Cylinder
Rotation Speed 45-75rpm
Rotary Torque 9000-10000N.m
Total Weight 10T
Operation Guide

Drill Pipe Addition Procedure:

  1. Stop propulsion, rotation, and cooling water when reaching drill pipe depth
  2. Retract chuck using fast backward handle
  3. Reverse gyrator while retracting feed oil cylinder
  4. Clamp drill pipe using gripper and open micro regulating flow valve
  5. Connect new drill pipe while advancing rotator
  6. Release gripper once threads engage
After-Sales Support
  • Comprehensive technical guidance for all machine operations
  • 24/7 multilingual customer support team
  • Custom construction solutions for various geological conditions
  • Long-term availability of all machine accessories
Frequently Asked Questions
Q: What types of drilling rigs do you offer?

A: We manufacture hydraulic drilling rigs, water well drilling rigs, core drilling rigs, and geological exploration rigs, with models tailored to specific requirements.

Q: Where is your manufacturing facility located?

A: Our factory is located in Jinzhou, Shijiazhuang City, Hebei Province, China.

Q: Are you a manufacturer or trading company?

A: We are an ISO-certified manufacturer with 20 years of experience and a modern production facility in Hebei.

Q: What is your typical delivery time?

A: Small hydraulic rigs ship in 5-7 days, large pneumatic rigs in 7-15 days. Expedited options available.

Q: What warranty do you provide?

A: The machine comes with a 1-year warranty (excluding consumable parts).
